2023 Volvo S60 Recharge Plug-in Hybrid Safety

2023 Volvo S60 Recharge Plug-in Hybrid pro



Safety

  • The vehicle is equipped with several safety systems that work together to protect the vehicle’s driver and passengers in the event of an accident.
  • The car is equipped with a number of sensors that react in the event of an accident and activate different safety systems, such as different types of airbags and seatbelt tensioners. Depending on the specific accident situation, such as collisions at different angles, roll-over or driving off the road, the systems react in different ways to provide good protection.
  • There are also mechanical safety systems such as Whiplash Protection System. The car is also constructed so that a large part of the force of a collision is distributed to beams, pillars, floor, roof and other parts of the body.
  • The car’s safety mode may be activated after a collision if an important function in the car has been damaged.
Warning symbol in driver display
2023-Volvo-S60-Recharge-Plug-in-Hybrid-Safety-fig-1
The warning symbol is illuminated in the driver display when the car’s electrical system is set in ignition position II. The symbol is extinguished after approx. 6 seconds if the car’s safety system is fault-free.

Warning

  • If the warning symbol remains illuminated or is switched on during driving and the message Drive to workshop SRS airbag Service urgent is shown in the driver display, it means that part of one of the safety systems does not have full functionality. Volvo recommends that an authorised Volvo workshop should be contacted as soon as possible.
  • Never modify or repair the car’s various safety systems yourself. Defective work in one of the systems can cause malfunction and result in serious personal injury. Volvo recommends that an authorised Volvo workshop should be contacted.

2023-Volvo-S60-Recharge-Plug-in-Hybrid-Safety-fig-2

If the specific warning symbol is broken then the general warning symbol is illuminated instead and the driver display shows the same message.

Pedestrian Protection System

  • The Pedestrian Protection System (PPS) is a system which, in certain frontal collisions, contributes to mitigating a pedestrian’s impact with the car.
  • In certain frontal collisions with a pedestrian, the sensors in the front of the car react and the system is activated.

When PPS is activated, the following occur:

  • The rear section of the bonnet is raised.
  • An automatic alarm is sent via Volvo Assistance.

The sensors are active at a speed of approx. 25-50 km/h (15-30 mph).

The sensors are designed to detect a collision with an object that has similar properties to those of the human leg.

Note

  • There may be objects in the traffic environment that prompt a signal to the sensors that is similar to a collision with a pedestrian. It is possible that the system will be activated in the event of a collision with such an object.

Warning

  • Do not fit any accessories or change anything in the front. Incorrect intervention at the front may cause incorrect function in the system and lead to serious injury and damage to the car.
  • Volvo recommends that genuine wiper arms are used and that only genuine parts are used for them.
  • Never modify or repair the system yourself. Volvo recommends that an authorised Volvo workshop should be contacted. Defective work in the system could cause malfunction and result in serious personal injury.
  • Volvo recommends contacting an authorised Volvo workshop in the event of any damage to the front of the car in order to ensure that the system is intact.
Symbols in the driver display
Symbol Specification
P5-1617-S90/V90–Safety–Symbol Pedestrian Protection System
PPS has been activated, or a fault has occurred in the system. Follow the recommendation given.

Safety during pregnancy

It is important that the seatbelt is used correctly during pregnancy, and that pregnant drivers adjust their seating position.
Seatbelt
P5-1507–Safety–Seat belt pregnancy
  • The diagonal section should wrap over the shoulder then be routed between the breasts and to the side of the abdomen.
  • The lap section should lay flat over the thighs and as low as possible under the abdomen. – It must never be allowed to ride upward. Remove the slack from the seatbelt and ensure that it fits as close to the body as possible. In addition, check that there are no twists in the seatbelt.
Seating position
As the pregnancy progresses, pregnant drivers must adjust the seat and steering wheel such that they can easily maintain control of the vehicle as they drive (which means that they must be able to easily operate the foot pedals and steering wheel). The aim should be to position the seat with as large a distance as possible between abdomen and steering wheel.

Whiplash Protection System

  • Whiplash Protection System (WHIPS) reduces the risk of whiplash injuries. The system consists of energy absorbing backrests and seat cushion, as well as a specially designed head restraint in the front seats.
  • WHIPS is deployed in the event of a rear-end collision, where the angle and speed of the collision and the nature of the colliding vehicle all have an influence.
  • When WHIPS is deployed, the front seat backrests are lowered backward and the seat cushions move downward to change the seating position of the driver and front seat passenger. Its movement helps to absorb some of the forces that can arise and cause whiplash.

Warning

  • WHIPS is a supplement to the seatbelts. Always use a seatbelt.
  • Never modify or repair the seat or WHIPS yourself. Volvo recommends that an authorised Volvo workshop should be contacted.
  • If the front seats have been subjected to a major load, such as in conjunction with a collision, the seats must be replaced. Some of the seats’ protective properties may have been lost even if they do not appear damaged.

P5-1507-Safety-Whiplash Protection System, don't leave any objects on floor or in seatsDo not leave any objects on the floor behind or under the front seats or in the rear seat that may prevent WHIPS from functioning.

Warning

  • Do not squeeze rigid objects between the rear seat cushion and the front seat’s backrest.
  • If a backrest in the rear seat is lowered then any load must be secured to prevent it from sliding up to the front seat backrest in the event of a collision.
  • If a backrest in the rear seat is lowered or a rear-facing child seat is used in the rear seat, the corresponding front seat must be moved forward so that it does not make contact with the lowered backrest or child seat.

Seating position

  • For good protection from WHIPS, the driver and passenger must have the correct seating position and make sure that the system’s function is not obstructed.
  • Set the correct seating position in the front seat before driving starts.
  • Driver and front-seat passenger should sit in the center of the seat with as little space as possible between the head and the head restraint.
WHIPS and child seats
The protection provided by the car to children seated in a child seat or on a booster cushion is not diminished by WHIPS.
