Driver display

The driver display shows information about the car and driving. The driver display contains gauges, indicators and indicator and warning symbols. The content of the driver display depends on the car’s equipment, settings and which functions are active at that time. The driver display is activated as soon as a door is opened, i.e. in ignition position 0. The driver display extinguishes after a while if it is not used. To reactivate it, proceed with one of the following:

  • Activate ignition position I.
  • Open one of the doors.
Warning
If the driver display should extinguish, not illuminate on activation/start or be fully or partially illegible, the car must not be used. You should visit a workshop immediately. Volvo recommends an authorised Volvo workshop.
Warning
In the event of a fault in the driver display the information on e.g. brakes, airbags or other safety systems may not be shown. In which case, the driver cannot check the status of the car’s systems or receive current warnings and information.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-1The figure is schematic – parts may vary depending on car model.

Location in the driver display:
On the left In the middle On the right
Speedometer Indicator and warning symbols Tachometer/ECO gauge (Depends on drive mode selected.)
Trip meter Outside temperature gauge Gear shift indicator
Odometer (Accumulated mileage.) Clock Drive mode
Cruise control and speed limiter information Messages, in some cases with graphics Fuel gauge
Road Sign Information (Accumulated mileage.) Door and seatbelt information Start/stop function status
Media player Distance to empty tank
Navigation map (Option/accessory.) Instantaneous fuel consumption
Phone App menu (activated via steering wheel keypad)
Voice control
Compass (Depends on drive mode selected.)

Dynamic symbol

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-2

The dynamic symbol in its basic form. The centre of the driver display contains a dynamic symbol that changes appearance for different types of message. An amber or red marker around the symbol indicates the degree of severity of a control or warning message.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-3Examples of indicator symbol. With an animation, the basic shape can be turned into a graphic showing where a problem is situated, or in order to clarify information.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-4The symbol in the driver display changes shape.

Driver display settings

Settings for the driver display’s display options can be made via the driver display’s app menu and via the centre display’s settings menu.

Settings via the driver display’s app menu

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-5The figure is schematic – parts may vary depending on car model. The app menu is opened and controlled using the right-hand keypad on the steering wheel. In the app menu, you can choose which information is shown on the driver display from:

  • trip computer
  • media player
  • phone
  • navigation system. (Option/accessory.)

Settings via the centre display

Selecting information type

  1. Tap on Settings in the centre display’s top view.
  2. Press My CarDisplaysDriver Display Information.
  3. Select what should be shown in the background:
    1. Show no information in background
    2. Show information for current playing media
    3. Show navigation even if no route is set
Selecting theme
  1. Tap on Settings in the centre display’s top view.
  2. Tap on My CarDisplaysDisplay Themes.
  3. Select a theme (appearance) for the driver display:
    1. Glass
    2. Minimalistic
    3. Performance
    4. Chrome Rings
Selecting language
  1. Tap on Settings in the centre display’s top view.
  2. Tap on SystemSystem Languages and UnitsSystem Language to select language.
    1. A change will affect the language in all displays.

These settings are personal and are saved automatically to the active driver profile.

Display texts in the driver display and centre display

Display texts in the driver and centre display that appear in the articles are listed in the table below.

Display text Meaning
Battery save mode Battery saving mode
12 V Battery 12 V battery
12 V Battery 12 V battery
30 minutes 30 minutes
30 sec 30 s
60 sec 60 s
90 sec 90 s
2nd row climate Second row climate control
3rd row climate Third row climate control
Abort Stop
AC AC
Accept Accept
Activate UNIT Activate UNIT
Activated Activated
Active Bending Lights Active bending lights
Active High Beam Active main beam
Adaptive Cruise Contr. Adaptive cruise control
Add as waypoint Set as intermediate destination
Add call Add call
Add device Add device
Add phone Add phone
Add timer Create new timer
Added Added
Additional Heater Additional heater
Address Address
Adjust Passenger Seat Adjust passenger seat
Adjust Passenger Seat From Driver Position Adapt the passenger seat according to the driver position
Advanced Advanced
Ahead Ahead
Air Quality Sensor Air quality sensor
Alarm Alarm
Alarm system failure Alarm system error
Alertness Warning Fatigue warning
All All
All Doors All doors
Allowed services for this device Permitted services for this device
Along route Along the route
Alternative Routes Alternative routes
Always Always
AM/FM radio AM/FM radio
Ambient Light Intensity Intensity for decor lighting
Ambient Light Level Level for decor lighting
Ambient Lighting Decor lighting
Answer Answer
Application updates Application updates
Apply steering Steer the car
Appointments Requests
Arrival Time Format Time format
Ask Question
Ask before connecting Ask before connecting
Steering aid during increased collision risk Steering assistance if there is an increased risk of collision
Road Sign Audio Warning Audible traffic signs warning
Auto Auto
Auto Activate Parking Brake Automatic activation of parking brake
Auto Camera Reverse Activation Activate camera when in reverse gear
Auto Close Sunroof Curtain Automatic closing of the sun blind
Rearview Mirror Auto Dimming Automatic dimming of rearview mirror
Auto Lock Doors While Driving Automatic locking of doors when driving
Auto Driver Seat Heating Level Start level, driver seat heater
Auto Front Defroster Automatic defroster windscreen
Auto Rear Defroster Automatic defroster rear
Auto fill Auto adjustment
Auto hold Auto hold
Auto Passenger Seat Heating Level Start level, passenger seat heater
Auto Rear Wiper Automatic wiping of rear window
Auto Segment Switching Automatic change of segment
Auto Software Update Background check for software updates
Auto Steering Wheel Heating Level Start level for automatic steering wheel heating
Auto update: Auto update:
City Safety City Safety
Auto Time Automatic time
Automatic Trailer Lamp Check Auto control of trailer lights
Automatically connect when I arrive Automatically connect when I arrive
Availability: Closed Availability: Closed
Availability: Crowded Availability: Almost full
Availability: Free Availability: Free
Availability: Full Availability: Full
Availability: Unknown Availability: Unknown
Avoid Avoid
Avoid Traffic Events Avoid traffic incidents
Back Backwards
Balance Balance
Base Map Version Version number for basic map
Bass Basic
Battery level sustained for later use Battery level is maintained for later use
Blind spot sensor Blind spot detector
Blind spot system off Blind spot detector off
Block Quarter
Blow into alcolock Blow into the alcohol lock
Book time for maintenance Book time for maintenance
Both Both
Brake Characteristics Braking properties
Brake pedal Brake pedal
Bright Lights
SOS/On Call button lock Keylock
By Temperature According to temperature
By Colour According to colour
Bypass instead? By-pass instead?
Store Pressure Save tyre pressure
Storing pressure unsuccessful. Try again. Calibrating not completed. Try again
Call Make call
Call to make Appointment Call to book time
Camera Camera
Cancel Stop
Cancel read out Cancel reading
Cancel request Cancel request
Cannot be selected because gear is in manual Not possible to select due to gear in manual mode
Cannot be selected because speed is too high Not possible to select due to speed too high
Cannot be selected due to limitations Not possible to select due to limitations
Cannot be selected due to low battery Not possible to select due to low battery level
Cannot be selected due to low temperature Not possible to select due to low temperature
Vehicle Identification Number Car’s identification number
Car key battery low Low battery in car key
Car key not found Remote control key not found
Car message stored in Car Status application Car message has been saved in Car Status app
Car Modem Internet Internet via car modem
Car not possible to start Car cannot be started
Car start Start of car
Car Status Car status
Car Trains Car train
Car Wi-Fi Hotspot Car’s Wi-Fi tethering
Card Status: Card status:
Change Switch
Change device Change device
Change PIN Change PIN code
Characteristics changed Service required Characteristics changed Service required
Charge cable Charging cable
Charging fault, low battery. Stop safely Charging fault, low battery. Stop ASAP
Charging complete Fully charged
Charging error Charging fault
Check tyres Check tyres
Check Car Status app in center display Check the tyres, calibrate after inflation
Cities Cities
City City
Clear itinerary Clear itinerary
Climate Climate
Close Close
Comfort Comfort
Communication Communication
Concert hall Concert hall
Confirm Confirm
Congestion Charge Zones Congestion charge areas
Connect Connect
Connect key Connect remote control key
Connected devices Connected devices
Coordinates and altitude Coordinates and altitude
Cornering Lights Cornering lights
Country Country
Create new Create new
Cruise Control Cruise control
Cushion extension Cushion extension
DAB To DAB Handover DAB to DAB link
DAB To FM Handover DAB to FM link
Dark Dark
Data roaming Data roaming
Data usage: %s Data usage: %s
Date Date
Date and Time Date and time
Day Day
Days Days
Deactivated Inactivated
Decline Decline
Disable Leveling Control Inactivation of level control
Choose Default Route Type Standard route types
Delete Delete
Destination: Destination:
Detour Detour
Disable PIN Inactivate SIM card PIN code
Displays Displays
Distance Distance
Doors and tailgate lock when the car moves Doors and tailgate locked when driving
Download Centre Download Center
Drive Preferences Driving preferences
Driver Driver
Driver Display Driver display
Driver Display Information Information in driver display
Driver Display Options Driver display options
Driver focused Focus driver
Single Door One door
Driver Performance Driver performance
Driver Profiles Driver profile
Driver support system Driver support functions
Driving Mode ECO Drive mode ECO
DSRC Uplink DSRC uplink
Dynamic Dynamic
Early Early
Easy Entry and Exit Suspension Control Shock absorption control for simple entry and exit
Easy Entry and Exit Seat Control Control for simple entry and exit
Eco ECO
Eco ECO
ECO Climate ECO climate control
Edit Edit
Edit list Edit list
Edit Profile Edit profile
Electric Electrical
Parking Brake and Suspension Parking brake and suspension
End call End call
Engine charges hybrid battery The petrol engine charges the hybrid battery
Engine coolant Coolant
Engine oil level Engine oil level
Engine oil level low Low engine oil level
Engine temperature Engine temperature
Ensembles Ensembles
Enter province Set province
Equaliser Equaliser
ESC Sport Mode ESC sport mode
Export Profile to USB Export profile to USB
Exterior Sound Exterior audio
Exterior Lights Exterior lighting
Factory reset Factory reset
Fast Fast
Favourites Favourites
Ferries Ferry
FM radio FM radio
FM Radio Manual Manual FM radio
FM Radio Settings Settings FM radio
Cornering Lights Cornering lights
Fold Headrest On Second Row Seats Lower head restraints on the second seat row
Fold Mirror When Locked Side mirrors angled in when locking
Forget Forget
Free Flow Information Information for free flow
Show Free Flowing Traffic Show free flowing traffic
Freeze Program Name Freeze programme service name
Frequency band Wavelength
Fuel lid will be unlocked when ready The fuel cap is opened
Fuel tank Fuel tank
Full Full
Fully charged at: Fully charged:
Fuse failure Service required Fuse blown Service required
Gear lever Gear lever
Gender Gender
Genres Genres
Factory reset Factory reset
Go here Drive here
Gracenote® Multiple Results Gracenote® several hits
Gracenote® Online Search Online search of Gracenote® in database
Guest Guest
Guidance Guidance
Guide Guide
half a day half day
Harsh behaviour at low speed, car ok to use Jerky running at low speed, OK to drive on
Head-up Display Head-up display
Head-up Display Adjustments Adjustments for head-up display
Head-Up Display Calibration Calibration for head-up display
Head-Up Display Options Head-up display alternative
Headrest Fold Lower head restraint
High High
High temperature Stop safely High temperature Stop safely
High temperature Turn off engine High temperature Stop the engine
Highways Motorway
Highway Facilities Motorway facilities
History History
Home Home
Home Safety Light Time Time for home safe lighting
HV battery Hybrid battery
Propulsion system Hybrid system
Hybrid system failure Hybrid system fault
Imperial British
Import Profile from USB Import profile from USB
Individual Drive Mode Individual drive mode
Individual stage Individual scene
Info card Information card
Install Install
Install all Install all
Intensity Intensity
Interior Lighting Interior lighting
Interior Mood Lighting Ambience lights
Interior Mood Light Intensity Strength of ambience light
International Borders Country border
Internet connection Internet connection
Graphic Message Graphic message
Text Message Text message
Join calls Merge calls
JP Traffic Information JP traffic information
Junction Junction
Keep climate comfort Retain climate comfort
Keyboard Layouts Keyboard layout
Keyless Unlock Keyless entry
Keypad Touch Keyboard sound
Lane Assistance Lane assistance
Lane Departure Warning Feedback Warning type for Lane Departure Warning
Lane Keeping Aid Mode Lane Keeping Aid mode
Lane Keeping Aid Warning Feedback Warning type for Lane Keeping Aid
System Language System language
Late Late
Left turn indicator malfunction Left direction indicators not working
Level low, turn off engine Low level, switch off engine
Level low, refill Level low Top up
Leveling Control Checking the level
Library Library
Lights and Lighting Beam and lighting
Light Lights
Lines Lines
Local Interruptions Local interruption
Locking Locking
Visible Locking Feedback Visible response when locking
Low Low
Low charge, temporarily reduced functionality Low charge, temporarily reduced functionality
For full functionality start car Low charge, will soon activate power saving mode
Lumbar Lumbar support
Lumbar Lumbar support
Main climate Main climate
Maintenance overdue Maintenance overdue
Major Larger
Make car discoverable Make car visible
Malfunction Function error
Manual Trailer Lamp Check Manual control of trailer lights
Manual tuning Manual setting
Map Map
Map Display Format Map design format
Map Information Map information
Maps Maps
Massage Massage
Max Max
Max car speed limited Limited max. speed
Media Media
Message Auto Read Auto reading of messages
Messages Messages
Metric Metric
Medium Medium
Mirrors and Convenience Mirrors and comfort
Medium Medium
More than one key is found, put the key you want to connect on backup reader More than one key was found. Place key you want to connect on the backup reader.
Highways Motorways
Name Name
Navi Voice Guidance Navigation voice
Navigation Settings Settings Navigation
Network Network
Network name Network name
New apps New apps
New message New message
New software updates available See Download Center Software updates are available
Never Never
Never connect and never ask Never connect and never ask
News News
News Flash News flow
Next Next
Next info Next info
Next page Next page
Night Night
No ETC history available No history
No value available No value available
None None
Normal Normal
Normal mode Normal mode
Notification in centre display Notifications in centre display
Notification in driver display Notifications in driver display
Number Number
Off Off
On On
Opening hours Opening hours
Ordinary Road Ordinary road
Owner’s manual Owner’s manual
Parallel parking Parallel parking
Park Assist Parking assistance
Park Assist System Park Assist
Park In Drive in
Park Out Drive out
Parking brake Parking brake
Parking climate Parking climate
Particulate filter full Particulate filter is full
Passenger Passengers
Passenger airbag off Passenger airbag Off
Passenger airbag on Passenger airbag On
Password Password
Perpendicular parking Perpendicular parking
Phone Phone
Picture format Pict. format
Please acknowledge Please confirm
POI Point Of Interest (POI)
POI Along Route Point Of Interest (POI) along the route
Position Format Position format
Position: Position:
Postcode Postcode
Powertrain Characteristics Properties for driveline
Preconditioning Preconditioning
Prefecture Prefecture
Preferences Preferences
Press brake pedal to activate gear lever Depress the brake to activate the gear lever
Previous info Earlier info
Previous page Previous page
Previously paired devices Previously connected devices
Audio Language Audio language
Subtitle Language Subtitle language
Privacy Private call
Private Locking Private locking
Profile Profile
Profile connected to key The profile is connected to the key
Profile Name Profile name
Protect Profile Protect profile
Province Province
Public General
Radio favourites Radio Favourites
Rain Sensor Memory Memory for rain sensor
Read out Read out
Ready for refuelling Ready for refuelling
Rear Rear
Rear child lock Rear child safety lock
Rear climate Rear climate control
Rear Sun Curtain Rear sun blind
Rear View Instead of 360° Rear view instead of 360°
Received Received
Recent Last
Recirc Recirc
Recirculation Timer Recirculation timer
Recom. Recom.
Care Key Care key
Care Keys Care keys
Reduce speed to lower temperature Reduce speed to lower the temperature
Reduced Reduced
Reduced functionality Service required Reduced functionality Service required
Reduced Guard Reduced alarm level
Reduced performance Reduced performance
Regular maintenance Regular service
Remote and Interior Unlock Remote-controlled and inside unlocking
Reject Decline
Remotely immobilised Remote controlled immobiliser
Remove before start Remove before starting
Remove device Remove device
Removed from car Removed from car
Repeat Voice Command Repeat voice command
Repeat weekly Repeat weekly
Request appoint. Create request
Reset Reset
Reset for all profiles Reset for all profiles
Reset for the active profile Reset for active profile
Reset Personal Settings Reset personal preferences
Rest Stop Guidance Guidance to rest area
Restart Restart
Request appointment Book workshop
Phone Ringtone Ring signal
Right turn indicator malfunction Right direction indicators not working
Ringtones Ring signals
Show Road Sign Information Show Road Sign Information
Traffic Flash Road traffic information
Route and Guidance Route and road navigation
Route Learning Route learning
Automatic intervention Automatic intervention
Safety mode Safety mode
Save Save
Save current settings to the profile Save current settings to your profile
Saved networks Saved networks
Scenic Picturesque
Screen Touch Touch sound
Search Search
Seats Seats
See Owner’s manual See Owner’s Manual
Select Announcements Select messages
Select network operator Select service provider
Send Send
Send appointment request Send appointment request
Send car data Send car data
Send new proposal Send new request
Send request code Send code for request
Sensor blocked, see Owner’s manual Detector blocked, see Owner’s Manual
Sensors blocked, cleaning needed Detectors blocked, cleaning required
Service required Service required
Service urgent Drive to workshop Service immediately Drive to workshop
Services Services
Set as home region Set as home region
Set dest. Specify destination
Set Home address Specify home address
Settings Settings
Shoulder Shoulder
Congestion Information Congestion information
Show Driver Support Show driver support
Show information for current playing media Show information about currently playing media
Show Map Show map
Show navigation even if no route is set Show navigation even when no route is set
Show Navigation Show navigation
Show no information in background Do not show any information in the background
Show on map Show on map
Show parking and status on map Show parking and status on map
Show Phone Show phone
Show Program Related Images Show programme-related images
Show Broadcast Information Show information from radio broadcast
Traffic Events Traffic events
Shuffle Shuffle
Side bolsters Side support
SIM card PIN SIM card PIN code
Similar Similar
Single Door One door
Slow Slow
Download Centre Download Center
Sort order for contacts Sort order for contacts
Sort Services Sort channel list
Sound Sound
Sound Experience Audio experience
Sound Experience Audio experience
Speech Rate Speaking rate
Speed Speed
Speed and Volume Compensation Speed and volume compensation
Show Speed Cameras Show speed cameras
Speed limit exceeded Max. speed exceeded
Speed Limit Warning Speed warning
Speed limitation cannot be exceeded Speed limit cannot be exceeded
Speed Sign Assist Speed limit assistance
SRS airbag SRS airbag
Apply steering Steer the car
Start navigation Start navigation
Start/Stop Start/Stop
State State
Stations Stations
Status Status
Status Of Parking Parking status
Assist Steering assistance
Steering Force Steering force
Stop safely Stop ASAP
Stop safely, wait for cooling Stop as soon as possible and let the gearbox cool
Storage Storage
Streets Streets
Studio Studio
Off Subtitles
Subwoofer Subwoofer
Suspension Suspension
Suspension Control Shock absorption control
Swap call Switch calls
Swell Swell
Switch to mobile phone Switch to mobile phone
Synchronise temperature Synchronising temperature
System System
System check, wait System check, please wait
System overheated System overheated
System updates System updates
System Version: System version:
System Volumes System volumes
Take me home Drive home
Tap to write information to the workshop Here you can write information to your workshop
Temporarily off Temporarily switched off
Temporarily unavailable Temporarily unavailable
Temporary Left Hand Traffic Temporary left-hand traffic
Temporary Right Hand Traffic Temporary right-hand traffic
Territory Area
Text message tone Signal for text message
Text Messages Text messages
The car is now in normal mode The car is now in normal mode
Theme Colours Theme colours
Display Themes Display themes
Auto Third Row Climate Automatic third row climate control start
This function requires an internet connection and your mobile phone subscription will be charged for data traffic This function requires an Internet connection, and data traffic costs will be charged to your mobile subscription
Exterior Mirror Tilt at Reverse Angling of side mirror when reversing
Time for a break soon? Time to take a break soon?
Time for maintenance Time for regular maintenance
Toll Customs
Toll Roads Toll roads
Tone Tone
Total capacity: Less than 20 Total capacity: Less than 20
Total capacity: Over 1000 Total capacity: More than 1000
Towbar Towbar
Town City/town
Traffic Traffic
Traffic Announcements Traffic message
Traffic Arrow/Icon Display Traffic messages from radio beacons
Show and Handle Traffic Events Show traffic events
Traffic Provider: %s Traffic provider: %s
Trailer attached Trailer connected
Trailer brake light Trailer brake lights
Trailer turn indicator Trailer direction indicators
Transmission hot Gearbox overheated
Transmission warm Transmission hot
Transport Flash Transport information
Tread Increasing
Treble Treble
Tunnels Tunnel
Turn off engine Stop engine
TV-channels TV channels
Tyre needs air now Tyres should be inflated
Tyre Pressure Units Tyre pressure units
Tyre pressure low Low tyre pressure
Tyre pressure system Tyre pressure system
Unavailable Not available
Unavailable Charge level too low Not available Charge level too low
Unavailable Fuel level too low Not available Fuel level too low
Unavailable Service required Not available Service required
Unavailable, fuel and charge level too low Not available, charge and fuel levels too low
Uninstall Uninstall
Units of Measurement Measurement units
Unlock All Doors Unlock all doors
US American
Vibration Vibration
VICS Archive VICS Archive
VICS congestion information VICS congestion information
VICS Display VICS Display
VICS FM VICS FM
VICS Interrupt VICS Interruption
VICS Motorway VICS Motorway
VICS Public VICS General
VICS Tuning VICS Setting
VICS Voice Guidance VICS voice guidance
Video Video
View old payments Read earlier ETC payments
Voice Control Voice control
Voice Guidance Level Level for voice guidance
Volvo Service Networks Volvo service network
Warning Warning
Warning/Services Warning/Services
Washer fluid Washer fluid
Welcome Light Approach light duration
Windscreen sensor Windscreen sensor
Wiper Service Position Service position for windscreen wiper
Wipers Windscreen wipers
Workshop Workshop
Workshop information Workshop information
Works only at certain speeds Only works at certain speeds
Zoom Zoom

License agreement for driver display

A license is an agreement for the right to operate a certain activity or the right to use someone else’s entitlement according to the terms and conditions in the agreement. The following text is Volvo’s agreement with the manufacturer or developer and is in English.

Freetype Project License

3rd Party Software Disclaimers and License Agreements Confidential ID 06-00004-004 39 / 75 Revision 06.00A, 2015-06-09 2006-Jan-27 Copyright 1996-2002, 2006 by David Turner, Robert Wilhelm, and Werner Lemberg.

Introduction
The FreeType Project is distributed in several archive packages; some of them may contain, in addition to the FreeType font engine, various tools and contributions which rely on, or relate to, the FreeType Project. This license applies to all files found in such packages, and which do not fall under their own explicit license. The license affects thus the FreeType font engine, the test programs, documentation and makefiles, at the very least. This license was inspired by the BSD, Artistic, and IJG (Independent JPEG Group) licenses, which all encourage inclusion and use of free software in commercial and freeware products alike. As a consequence, its main points are that: o We don’t promise that this software works. However, we will be interested in any kind of bug reports. (`as is’ distribution) o You can use this software for whatever you want, in parts or full form, without having to pay us. (`royalty-free’ usage) o You may not pretend that you wrote this software. If you use it, or only parts of it, in a program, you must acknowledge somewhere in your documentation that you have used the FreeType code. (`credits’) We specifically permit and encourage the inclusion of this software, with or without modifications, in commercial products. We disclaim all warranties covering The FreeType Project and assume no liability related to The FreeType Project. Finally, many people asked us for a preferred form for a credit/disclaimer to use in compliance with this license. We thus encourage you to use the following text: “Portions of this software are copyright © 2013 The FreeType Project (www.freetype.org). All rights reserved.”
Legal Terms
  1. Definitions – Throughout this license, the terms `package’, `FreeType Project’, and `FreeType archive’ refer to the set of files originally distributed by the authors (David Turner, Robert Wilhelm, and Werner Lemberg) as the `FreeType Project’, be they named as alpha, beta or final release. `You’ refers to the licensee, or person using the project, where `using’ is a generic term including compiling the project’s source code as well as linking it to form a `program’ or `executable’. This program is referred to as `a program using the FreeType engine’. This license applies to all files distributed in the original FreeType Project, including all source code, binaries and documentation, unless otherwise stated in the file in its original, unmodified form as distributed in the original archive. If you are unsure whether or not a particular file is covered by this license, you must contact us to verify this. The FreeType Project is copyright (C) 1996-2000 by David Turner, Robert Wilhelm, and Werner Lemberg. All rights reserved except as specified below.
  2. No Warranty – THE FREETYPE PROJECT IS PROVIDED `AS IS’ WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT WILL ANY OF THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY DAMAGES CAUSED BY THE USE OR THE INABILITY TO USE, OF THE FREETYPE PROJECT. ‘
  3. Redistribution – This license grants a worldwide, royalty-free, perpetual and irrevocable right and license to use, execute, perform, compile, display, copy, create derivative works of, distribute and sublicense the FreeType Project (in both source and object code forms) and derivative works thereof for any purpose; and to authorize others to exercise some or all of the rights granted herein, subject to the following conditions: o Redistribution of source code must retain this license file (`FTL.TXT’) unaltered; any additions, deletions or changes to the original files must be clearly indicated in accompanying documentation. The copyright notices of the unaltered, original files must be preserved in all copies of source files. o Redistribution in binary form must provide a disclaimer that states that the software is based in part of the work of the FreeType Team, in the distribution documentation. We also encourage you to put an URL to the FreeType web page in your documentation, though this isn’t mandatory. These conditions apply to any software derived from or based on the FreeType Project, not just the unmodified files. If you use our work, you must acknowledge us. However, no fee need be paid to us.
  4.  Advertising – Neither the FreeType authors and contributors nor you shall use the name of the other for commercial, advertising, or promotional purposes without specific prior written permission. We suggest, but do not require, that you use one or more of the following phrases to refer to this software in your documentation or advertising materials: `FreeType Project’, `FreeType Engine’, `FreeType library’, or `FreeType Distribution’. As you have not signed this license, you are not required to accept it. However, as the FreeType Project is copyrighted material, only this license, or another one contracted with the authors, grants you the right to use, distribute, and modify it. Therefore, by using, distributing, or modifying the FreeType Project, you indicate that you understand and accept all the terms of this license.
  5. Contacts – There are two mailing lists related to FreeType: o freetype@nongnu.org. Discusses general use and applications of FreeType, as well as future and wanted additions to the library and distribution. If you are looking for support, start in this list if you haven’t found anything to help you in the documentation. o freetype-devel@nongnu.org. Discusses bugs, as well as engine internals, design issues, specific licenses, porting, etc. Our home page can be found at http://www.freetype.org

HarfBuzz / UCDN License

  • Copyright © 2010,2011,2012 Google, Inc.
  • Copyright © 2012 Mozilla Foundation
  • Copyright © 2011 Codethink Limited
  • Copyright © 2008,2010 Nokia Corporation and/or its subsidiary(-ies)
  • Copyright © 2009 Keith Stribley
  • Copyright © 2009 Martin Hosken and SIL International
  • Copyright © 2007 Chris Wilson
  • Copyright © 2006 Behdad Esfahbod
  • Copyright © 2005 David Turner
  • Copyright © 2004,2007,2008,2009,2010 Red Hat, Inc.
  • Copyright © 1998-2004 David Turner and Werner Lemberg

For full copyright notices consult the individual files in the package. Permission is hereby granted, without written agreement and without license or royalty fees, to use, copy, modify, and distribute this software and its documentation for any purpose, provided that the above copyright notice and the following two paragraphs appear in all copies of this software. IN NO EVENT SHALL THE COPYRIGHT HOLDER BE LIABLE TO ANY PARTY FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS SOFTWARE AND ITS DOCUMENTATION, EVEN IF THE COPYRIGHT HOLDER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. THE COPYRIGHT HOLDER SPECIFICALLY DISCLAIMS ANY WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE SOFTWARE PROVIDED HEREUNDER IS ON AN “AS IS” BASIS, AND THE COPYRIGHT HOLDER HAS NO OBLIGATION TO PROVIDE MAINTENANCE, SUPPORT, UPDATES, ENHANCEMENTS, OR MODIFICATIONS.

Libunibreak License

This library is released under an open-source licence, the zlib/libpng licence. Please check the file LICENCE for details. Apart from using the algorithm, part of the code is derived from the data provided under http://www.unicode.org/Public. And the Unicode Terms of Use may apply: URL:http://www.unicode.org/copyright.html

LICENSE:

  • Copyright (C) 2008-2012 Wu Yongwei <wuyongwei at gmail dot com>
  • Copyright (C) 2012 Tom Hacohen <tom dot hacohen at samsung dot com>

This software is provided ‘as-is’, without any express or implied warranty. In no event will the author be held liable for any damages arising from the use of this software. Permission is granted to anyone to use this software for any purpose, including commercial applications, and to alter it and redistribute it freely, subject to the following restrictions:

  1. The origin of this software must not be misrepresented; you must not claim that you wrote the original software. If you use this software in a product, an acknowledgement in the product documentation would be appreciated but is not required.
  2. Altered source versions must be plainly marked as such, and must not be misrepresented as being the original software.
  3. This notice may not be removed or altered from any source distribution.
Unicode Inc. License Agreement
EXHIBIT 1 UNICODE, INC. LICENSE AGREEMENT – DATA FILES AND SOFTWARE Unicode Data Files include all data files under the directories http://www.unicode.org/Public/, http://www.unicode.org/reports/, and http://www.unicode.org/cldr/data/ . Unicode Software includes any source code published in the Unicode Standard or under the directories http://www.unicode.org/Public/, http://www.unicode.org/reports/, and http://www.unicode.org/cldr/data/. NOTICE TO USER: Carefully read the following legal agreement. BY DOWNLOADING, INSTALLING, COPYING OR OTHERWISE USING UNICODE INC.’S DATA FILES (“DATA FILES”), AND/OR SOFTWARE (“SOFTWARE”), YOU UNEQUIVOCALLY ACCEPT, AND AGREE TO BE BOUND BY, ALL OF THE TERMS AND CONDITIONS OF THIS AGREEMENT. IF YOU DO NOT AGREE, DO NOT DOWNLOAD, INSTALL, COPY, DISTRIBUTE OR USE THE DATA FILES OR SOFTWARE. COPYRIGHT AND PERMISSION NOTICE Copyright © 1991-2010 Unicode, Inc. All rights reserved. Distributed under the Terms of Use in http://www.unicode.org/copyright.html. Permission is hereby granted, free of charge, to any person obtaining a copy of the Unicode data files and any associated documentation (the “Data Files”) or Unicode software and any associated documentation (the “Software”) to deal in the Data Files or Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, and/or sell copies of the Data Files or Software, and to permit persons to whom the Data Files or Software are furnished to do so, provided that (a) the above copyright notice(s) and this permission notice appear with all copies of the Data Files or Software, (b) both the above copyright notice(s) and this permission notice appear in associated documentation, and (c) there is clear notice in each modified Data File or in the Software as well as in the documentation associated with the Data File(s) or Software that the data or software has been modified. THE DATA FILES AND SOFTWARE ARE PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF THIRD PARTY RIGHTS. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR HOLDERS INCLUDED IN THIS NOTICE BE LIABLE FOR ANY CLAIM, OR ANY SPECIAL INDIRECT OR CONSEQUENTIAL DAMAGES, OR ANY DAMAGES WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THE DATA FILES OR SOFTWARE. Except as contained in this notice, the name of a copyright holder shall not be used in advertising or otherwise to promote the sale, use or other dealings in these Data Files or Software without prior written authorization of the copyright holder.
ZLIB Data Compression Library License Agreement

(C) 1995-2010 Jean-loup Gailly and Mark Adler This software is provided ‘as-is’, without any express or implied warranty. In no event will the authors be held liable for any damages arising from the use of this software. Permission is granted to anyone to use this software for any purpose, including commercial applications, and to alter it and redistribute it freely, subject to the following restrictions:

  1. The origin of this software must not be misrepresented; you must not claim that you wrote the original software. If you use this software in a product, an acknowledgment in the product documentation would be appreciated but is not required.
  2. Altered source versions must be plainly marked as such, and must not be misrepresented as being the original software.
  3. This notice may not be removed or altered from any source distribution.

Jean-loup Gailly Mark Adler jloup@gzip.org madler@alumni.caltech.edu If you use the zlib library in a product, we would appreciate *not* receiving lengthy legal documents to sign. The sources are provided for free but without warranty of any kind. The library has been entirely written by Jean-loup Gailly and Mark Adler; it does not include third-party code. If you redistribute modified sources, we would appreciate that you include in the file ChangeLog history information documenting your changes. Please read the FAQ for more information on the distribution of modified source versions.

GLEW Licence (Modified BSD Licence)

The OpenGL Extension Wrangler Library

  • Copyright (C) 2002-2008, Milan Ikits <milan.ikits@ieee org>
  • Copyright (C) 2002-2008, Marcelo E. Magallon <mmagallo@debian.org>
  • Copyright (C) 2002, Lev Povalahev

All rights reserved.

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. * Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. * The name of the author may be used to endorse or promote products derived from this software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

App menu in the driver display

The app menu in the driver display provides quick access to commonly used functions for certain apps.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-6The figure is schematic.

The app menu in the driver display can be used instead of the centre display and is controlled using the right-hand keypad on the steering wheel. The app menu makes it easier to switch between different apps or functions within the apps without having to let go of the steering wheel.

App menu functions

Different apps give access to different types of functions. The following apps and their associated functions can be controlled from the app menu:

App Functions
Trip computer Selection of trip meter, selection of what to show in the driver display, etc.
Media player Selection of active source for the media player.
Phone Calling a contact from the call list.
Navigation Guide to destination, etc.

Managing the app menu in the driver display

The app menu in the driver display is operated with the steering wheel’s right-hand keypad.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-7The app menu and the steering wheel’s right-hand keypad. The figure is schematic.

  1. Open/close
  2. Left/right
  3. Up/down
  4. Confirm
Opening/closing the app menu

Press on open/close (1). The app menu opens/closes.

Note
 It is not possible to open the app menu while there is an unacknowledged message in the driver display. The message has to be confirmed first before the app menu can be opened. The app menu closes automatically after a period of inactivity or after certain options have been selected.

Navigating and selecting in the app menu

  1. Navigate between the apps by pressing on the left or right (2).
    1. Functions for previous/next app are shown in the app menu.
  2. Browse through the functions for the selected app by tapping on up or down (3).
  3. Confirm or highlight an option for the function by pressing on confirm (4).
    1. The function is activated and for some options the app menu then closes.

If the app menu is opened again, the functions of the most recently selected app are shown first.

Indicator and warning symbols

The indicator and warning systems alert the driver to the fact that a function is activated, a system is working, or a defect or serious error has occurred.

Red symbols
2022-Volvo-XC40-Your-Volvo-Driver-display-fig-8



Warning

The red warning symbol illuminates when a fault has been detected which could affect the safety or drivability of the car. An explanatory text is shown on the driver display at the same time.

The warning symbol can also illuminate in conjunction with other symbols.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-9
Seatbelt reminder

Illuminates or flashes when someone in the car is not wearing a seatbelt.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-10
Airbags

An error has been detected in any of the car’s safety systems.

Read the message on the driver display and contact a workshop. Volvo recommends that an authorised Volvo workshop is contacted.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-11
Fault in brake system

An error has occurred on the braking system.

Read the message on the driver display and contact a workshop. Volvo recommends that an authorised Volvo workshop is contacted.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-12
Parking brake

Light illuminated permanently: The parking brake is activated.

Flashing: an error has occurred with the parking brake. Read the message in the driver display.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-13
Faults in the electrical system

An error has occurred on the electrical system.

Read the message on the driver display and contact a workshop. Volvo recommends that an authorised Volvo workshop is contacted.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-14
High engine temperature

The engine temperature is too high. Read the message in the driver display.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-15
Collision risk

City Safety warns of a risk of collision with other vehicles, pedestrians, cyclists or large animals.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-16
Low oil pressure

The engine oil pressure is too low. Switch off the engine immediately and check the engine oil level, top up if necessary.

If the symbol lights up and the oil level is normal, read the message on the display and contact a workshop. Volvo recommends that an authorised Volvo workshop is contacted.



Amber symbols
2022-Volvo-XC40-Your-Volvo-Driver-display-fig-17
Information

A fault has occurred in one of the car’s systems. Read the message in the driver display.

The information symbol can also illuminate in conjunction with other symbols.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-18
Fault in brake system

An error has occurred on the braking system. Read the message in the driver display.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-19
ABS fault

The system is disengaged. The car’s regular brake system continues to work, but without the ABS function.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-20
Emissions system

Emissions systems fault. Drive to a workshop for checking. Volvo recommends that an authorised Volvo workshop is contacted.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-21
Rear fog lamp

The rear fog lamp is illuminated.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-22
Tyre pressure system

Low tyre pressure.

If there is a fault in the tyre pressure system, the symbol will flash for approx. 1 minute and then illuminate with a constant glow. This may be because the system cannot detect or warn of low tyre pressure as intended.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-23
Fault in the headlamp system

A fault has occurred on the headlamp system. Read the message in the driver display.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-24
Lane assistance

Lane assistance warns/intervenes.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-25
Stability system

Light on permanently: a fault has occurred in the system.

Flashing: the system is working.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-26
Stability system, sport mode

Sport mode is selected.

Blue symbols
2022-Volvo-XC40-Your-Volvo-Driver-display-fig-27
Active main beam

Active main beam is activated and switched on.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-28
Main beam

Main beam is switched on.

Green symbols
2022-Volvo-XC40-Your-Volvo-Driver-display-fig-29
Automatic brake

The function is activated and the service brake or parking brake is operating.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-30
Front fog lamps

The front fog lamp is switched on.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-31
Position lamps

The position lamps are switched on.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-32
Left and right-hand direction indicator

The direction indicator is being used.

White/grey symbols
2022-Volvo-XC40-Your-Volvo-Driver-display-fig-33
Active main beam

Active main beam is activated, but does not come on.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-34
Preconditioning

Engine and compartment heater/air conditioning pre-condition the car.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-35
Lane assistance

White symbol: Lane assistance is on and road lines are detected.

Grey symbol: Lane assistance is on but road lines are not detected.

P5-1507 Symbol Rain sensor
Rain sensor

The rain sensor is activated.

Messages in the driver display

The driver display can show messages to inform or assist the driver in the event of different events.

2022-Volvo-XC40-Your-Volvo-Driver-display-fig-37
Example of message in the 8-inch driver display. The figure is schematic – parts may vary depending on car model.
2022-Volvo-XC40-Your-Volvo-Driver-display-fig-38
Examples of messages in the driver display. The figure is schematic – parts may vary depending on car model. The driver display shows messages that are of high priority for the driver. Messages can be shown in different parts of the driver display depending on what other information is currently being displayed. After a while, or when the message has been acknowledged/action taken if required, the message disappears from the driver display. If a message needs to be saved, it is placed in the Car Status app, which is opened from the app view in the centre display. Message composition may vary and they can be shown together with graphics, symbols or buttons for acknowledging the message or accepting a request, for example.
Service messages
Shown below is a selection of important service messages and their meanings.
Message Specification
Stop safely (Part of message, shown together with information on where the problem has arisen.) Stop and switch off the engine. Serious risk of damage – consult a workshop. (An authorised Volvo workshop is recommended.)
Turn off engine (Part of message, shown together with information on where the problem has arisen.) Stop and switch off the engine. Serious risk of damage – consult a workshop. (An authorised Volvo workshop is recommended.)
Service urgent Drive to workshop (Part of message, shown together with information on where the problem has arisen.) Contact a workshop (An authorised Volvo workshop is recommended.) to check the car immediately.
Service required (Part of message, shown together with information on where the problem has arisen.) Contact a workshop (An authorised Volvo workshop is recommended.) to check the car as soon as possible.
Regular maintenance

Book time for maintenance

Time for regular service – contact a workshop. (An authorised Volvo workshop is recommended.) Shown before the next service date.
Regular maintenance

Time for maintenance

Time for regular service – contact a workshop. (An authorised Volvo workshop is recommended.) Shown at the next service date.
Regular maintenance

Maintenance overdue

Time for regular service – contact a workshop. (An authorised Volvo workshop is recommended.) Shown when the service date has passed.
Temporarily off (Part of message, shown together with information on where the problem has arisen.) A function has been temporarily switched off and is reset automatically while driving or after starting again.

Leave a Comment
