FUSE BOX LOCATIONS
Engine Compartment Fuse Box
The fuse box is located in the engine compartment. See Maintenance.
Passenger Compartment Fuse Box
The fuse box is located below the glove box.
Luggage Compartment Fuse Box
The fuse box is located in the luggage compartment on the right-hand side. Remove the fuse box cover to gain access to the fuses.
FUSE SPECIFICATION CHART
Engine Compartment Fuse Box
| Fuse Number | Fuse Rating | Protected Component |
|---|---|---|
| F1 | – | Not used. |
| F2 | – | Not used. |
| F3 | – | Not used. |
| F4 | – | Not used. |
| F5 | – | Not used. |
| F6 | – | Not used. |
| F7 | 40 A | Anti-lock brake system. |
| F8 | 30 A | Stability control. |
| F9 | 30 A | Heated rear window. |
| F10 | 40 A | Blower motor. |
| F11 | 40 A | Accessories – Van only. |
| F12 | 30 A | Powertrain control module. |
| F13 | 30 A | Starter relay. |
| F14 | 40 A | Right-hand heated windshield. |
| F15 | 20 A | Cargo-area auxiliary power point. Luggage compartment auxiliary power point. |
| F16 | 40 A | Heated windshield. |
| F17 | 20 A | Floor console auxiliary power point. |
| F18 | – | Not used. |
| F19 | 5 A | Anti-lock brake system with electronic stability control. |
| F20 | 15 A | Horn. |
| F21 | 5 A | Stop lamp switch. |
| F22 | 10 A | Power supply voltage – powertrain control module. |
| F23 | 5 A | Relay coils. |
| F24 | – | Not used. |
| F25 | 25 A | Door control unit – Van. |
| F26 | 5 A | Engine control relay coil feed. |
| F27 | 15 A | Air conditioning clutch. |
| F28 | 25 A | Rear power window. |
| F29 | 25 A | Front power window. |
| F30 | 5 A | Ignition switch position II output (van only). |
| F31 | 15 A | Taxi roof lamp switch. |
| F32 | 15 A | Engine control module. |
| F33 | 10 A | Engine control module. |
| F34 | 10 A | Fuel injectors. |
| F35 | 15 A | Vehicle power 4. |
| F36 | 5 A | Active grill shutter. |
| F37 | 5 A | Battery saver relay. |
| F38 | 15 A | Engine control module. Transmission control module. |
| F39 | 10 A | Taxi block connector. |
| F40 | 5 A | Electronic power assist steering. |
| F41 | 20 A | Body control module. |
| F42 | 15 A | Rear window wiper. |
| F43 | 15 A | Heated front seat – Van. |
| 20 A | Accessories – Van. | |
| F44 | 15 A | Headlamp control module. |
| 5 A | Air conditioning switch – Taxi. | |
| F45 | 10 A | Power exterior mirror – without door control unit. |
| F46 | 40 A | Windshield wiper. |
| F47 | 7.5 A | Heated exterior mirror – without door control unit. |
| F48 | 25 A | Body control module. |
| Relay Number | Circuits switched |
|---|---|
| R1 | Not used. |
| R2 | Horn. |
| R3 | Battery saver relay. |
| R4 | Heated rear window. |
| R5 | Rear window wiper. |
| R6 | Not used. |
| R7 | Heated windshield. |
| R8 | Accessory delay. DCU power feed – Van. |
| R9 | Relay – Van. |
| R10 | Starter motor. |
| R11 | Air conditioning clutch. |
| R12 | Cooling fan. |
| R13 | Blower motor. |
| R14 | Electronic engine control. |
| R15 | Not used. |
| R16 | Ignition. |
Passenger Compartment Fuse Box
| Fuse Number | Fuse Rating | Protected Component |
|---|---|---|
| F56 | 20 A | Fuel pump. |
| F57 | – | Not used. |
| F58 | – | Not used. |
| F59 | 5 A | Passive anti-theft system transceiver. |
| F60 | 10 A | Interior lamp. Driver door switch pack. Glove compartment lamp. Overhead console switch bank. |
| F61 | 20 A | Not used. |
| F62 | 5 A | Autowipers. Auto-dimming interior mirror. |
| F63 | – | Not used. |
| F64 | – | Not used. |
| F65 | 10 A | Liftgate release. |
| F66 | 20 A | Front door double locking and unlock relay. |
| F67 | 7.5 A | SYNC module. Front display interface module. Global positioning system module. |
| F68 | – | Not used. |
| F69 | 5 A | Instrument panel cluster. |
| F70 | 20 A | Central locking relay. |
| F71 | 10 A | Heating control head (manual air conditioning). Dual automatic temperature control. |
| F72 | 7.5 A | Steering wheel module. |
| F73 | 7.5 A | Data link connector. Battery backup sounder. |
| F74 | 15 A | High beam headlamp. |
| F75 | 15 A | Front fog lamp. |
| F76 | 10 A | Reversing lamp. |
| F77 | 20 A | Washer pump. |
| F78* | 5 A | Ignition switch. |
| F79 | 15 A | Audio unit. DVD navigation system. Touchscreen. Hazard flasher switch. Door lock switch. |
| F80 | – | Not used. |
| F81 | 5 A | Power sunroof. |
| Interior motion sensor. | ||
| F82 | 20 A | Washer pump. |
| F83 | 20 A | Central locking. |
| F84 | 20 A | DD FF unlock supply (ground fuse). DD FF double lock (ground fuse). |
| F85 | 7.5 A | Ignition switch. |
| F86 | 10 A | Airbag module. Occupant classification system. Passenger airbag deactivation switch. |
| F87 | – | Not used. |
| F88 | – | Not used. |
| F89 | – | Not used. |
Cargo Compartment Fuse Box
| Fuse Number | Fuse Rating | Protected Component |
|---|---|---|
| F1 | 10 A | Rear heating, ventilation and air conditioning. |
| F2 | 25 A | Driver seat adjuster. |
| F3 | 25 A | Driver door module. |
| F4 | 25 A | Passenger door module. |
| F5 | – | Not used. |
| F6 | 25 A | Door control unit rear left. |
| F7 | 25 A | Door control unit rear right. |
| F8 | – | Not used. |
| F9 | – | Not used. |
| F10 | – | Not used. |
| F11 | – | Not used. |
| F12 | – | Not used. |
| F13 | – | Not used. |
| F14 | – | Not used. |
| F15 | – | Not used. |
| F16 | – | Not used. |
| F17 | – | Not used. |
| F18 | – | Not used. |
| F19 | – | Not used. |
| F20 | – | Not used. |
| F21 | – | Not used. |
| F22 | – | Not used. |
| F23 | – | Not used. |
| F24 | – | Not used. |
| F25 | 40 A | Rear blower motor. |
| F26 | 40 A | Accessories. Trailer tow module. |
| F27 | 40 A | Taxi. |
| F28 | – | Not used. |
| F29 | 5 A | Rear view camera. |
| F30 | 5 A | Parking aid. |
| F31 | – | Not used. |
| F32 | – | Not used. |
| F33 | – | Not used. |
| F34 | 15 A | Driver heated seat. |
| F35 | 15 A | Passenger heated seat. |
| F36 | – | Not used. |
| F37 | 20 A | Power sunblind. |
| F38 | 10 A | Taxi. |
| F39 | – | Not used. |
| F40 | – | Not used. |
| F41 | 10 A | Taxi connector. |
| F42 | 20 A | Taxi connector. |
| F43 | – | Not used. |
| F44 | – | Not used. |
| F45 | – | Not used. |
| F46 | – | Not used. |
| Relay Number | Circuits switched |
|---|---|
| R1 | Ignition switch. |
| R2 | Rear heating, ventilation and air conditioning. Ventilation and air conditioning motor. |
| R3 | Not used. |
| R4 | Not used. |
| R5 | Not used. |
| R6 | Not used. |
CHANGING A FUSE
Fuses
 WARNING: Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. |
If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components.
Fuse Types:
| Callout | Fuse Type |
|---|---|
| A | Micro 2 |
| B | Micro 3 |
| C | Maxi |
| D | Mini |
| E | M Case |
| F | J Case |
| G | J Case Low Profile |
